HP Desktop PCs – motherboard specifications, Sunflower

Figure : The Sunflower motherboard

Motherboard description

• HP name: Sunflower
• SSID: 8433

Form Factor

• Customised size: 24.4×26.7 cm (9.6×10.5 in)

Chipset

• AMD Promontory FCH

Processor upgrade information

• TDP: up to 65 W
• Socket type: AM4
• Motherboard supports the following processor upgrades:

• Processor

  TDP

  AMD Ryzen7-2700 (Pinnacle Ridge) 8 cores/16 threads	65 W
  AMD Ryzen5-2600 (Pinnacle Ridge) 6 cores/12 threads	65 W
  AMD Ryzen7-1700 (Summit Ridge) 3.0 GHz, 8 cores/16 threads	65 W
  AMD Ryzen5-1600 (Summit Ridge) 3.2 GHz, 6 cores/12 threads	65 W
  AMD Ryzen5-2400G (Raven Ridge) 3.6 GHz, 4 cores/8 threads	45 – 65 W
  AMD Ryzen3-2200G (Raven Ridge) 3.5 GHz, 4 cores/4 threads	45 – 65 W
  AMD AMD A12-9800 APU (Bristol Ridge) 3.8 GHz, 4 cores	65 W
  AMD AMD A10-9700 APU (Bristol Ridge) 3.5 GHz, 4 cores	65 W
  AMD AMD A8-9600 APU (Bristol Ridge) 3.1 GHz, 4 cores	65 W

Memory upgrade information

• Dual channel (2 DIMMs per channel) memory architecture
• Two DDR4 UDIMM (288-pin) sockets
• Supports PC4-19200 (DRR4-2400)
• Supports 4 GB and 8 GB DDR4 UDIMMs
• Supports up to 4 GB on 32-bit systems
• NOTE: 32-bit systems cannot address a full 4.0 GB of memory.
• Supports up to 32 GB (unbuffered) on 64-bit computers
• NOTE: Maximum memory shown reflects the capability of the hardware and can be limited further in the operating system.

Video

Integrated graphics

Audio

Integrated audio

Network

LAN: 1000BASE-T

Expansion Slots

• One PCIe x16 slot
• One PCIe x1 slot
• One M.2 socket 1, key A
• One M.2 socket 3, key M

I/O Ports and Jumpers

Back I/O ports

NOTE:

The configuration might vary depending on your model (for example, if a dedicated graphics card is included). Any modifications or upgrades might change the configuration, port accessibility, and port functionality.

Figure : Sunflower back I/O panel

1. Audio Line-in
2. Speakers
3. Microphone jack
4. HDMI
5. VGA
6. LAN (Ethernet)
7. USB 2.0
8. USB 3.1

Jumpers

Figure : Clear password jumper in the default position

Figure : Clear CMOS jumper in the default position
